Description
The model No. of PA66 GF15 Halogen Free Flame Retardant
JL2015GC-FR-HF
The main feature
PA66 with 15% Glass Fiber reinforced, halogen free flame retardant
The application
Connectors, terminal block, electrical switch.
The properties of PA66 GF15 Halogen Free Flame Retardant
| Properties | Index | Test Standard | Figures |
| Mechanical Properties | Tensile Strength | ASTM D638 (Mpa) | 110 |
| Tensile Modulus | ASTM D638 (Mpa) | 7000 | |
| Flexural Strength | ASTM D790 (Mpa) | 165 | |
| Flexural Modulus | ASTM D790 (Mpa) | 6000 | |
| Impact Strength | ASTM D256 (J/m) | 60 | |
| Thermal Properties | Heat Distortion Temperature | ASTM D648 (℃） | 235 |
| Mold Shrinkage | ASTM D955 （%） | 0.3-0.6 | |
| Forming Temperature | （℃） | 270-290 | |
| Others | Proportion | ASTM D792 | 1.32 |
| Water Absorption | ASTM D570 （%) | 2.0 |
